Overview
The perfect companion for your project workspace, the M510 delivers high-volume, high-quality labels day in and day out. Whether you're in a lab, field or facility, this printer works as hard as you do.
- Create large 1.5" labels with edge-to-edge printing and a wide range of text sizes
- Print up to 1.5" per second to get work done faster
- Use the M510 for more applications with 250+ hassle-free drop-in cartridges and 26+ high-performance materials
- Enter data with more accuracy as you work between an intuitive QWERTY keypad, a separate numeric keypad or a PC
- Backlit full-color LCD graphics display for easier labeling in low-lit areas
- Durably designed to withstand 4' drops
- The rechargeable NiMH battery prints up to 1700 labels on a single charge
-
Design and print labels from a PC using Brady Workstation Software
Click Here For M510 Label Cartridges
| Key Characteristics | |
| Product Number | 176546 |
| UPC | 888434624289 |
| UOM | Each |
| Trade Name | M510 |
| Brand Name | Brady® |
| Dimensions | |
| Dimensions | 3.75 in H x 5.75 in W x 10 in D |
| Height | 3.75 in |
| Width | 5.75 in |
| Depth | 10 in |
| Display Size | 2.8 in |
| Weight | 3.05 lb |
| Material Characteristics | |
| Color | Blue, Gray |
| Product Features | |
| Application | Asset Tracking, Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, Facility Identification, General Identification, Inventory and Inspection Labeling, Laboratory Labeling, Lean and 5S Labeling, Safety Identification, Warehouse Marking, Wire and Cable Labeling |
| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped installed in equipment |
| Battery mAh Rating | 1200 mAh |
| Battery Weight | 0.51 lb |
| Built-In Label Wizards | 66 Block, Breaker Box, DesiStrip, Face Plate, Flags, General, Patch Panel, Terminal Block, Vial, Wire Wrap |
| Connectivity Options | USB |
| Cutter Type | Single Hand Manual Actuate, Straight Cut, With label retention |
| Device Connectivity | PC connected, Stand-alone |
| Device Drop Test & Durability | Resistant to 4-foot drops |
| Display Type | Color LCD Screen, LCD backlit graphics display |
| Keyboard Type | QWERTY |
| Memory | 512 MB RAM, 256 MB Flash |
| Number of Symbols | 480 |
| On Screen Indicators | Battery Life, Ribbon and label part number recognition, Supply Remaining |
| Plug Type | US |
| Power Supply Voltage | 110 - 240 V |
| Auto Shut-Off / Power Conserve | 10 minutes, User Configurable |
| Recharge Time | 4 hours |
| Special Characters Quantity | 123 |
| User Interface Type | Full QWERTY Keyboard, PC |
| Battery Type | Rechargeable NiMH Battery |
| Printing Specifications | |
| Barcode Symbologies - 2D | Data Matrix, QR code |
| Barcode Symbologies - Linear | Code 128, Code 39, EAN-13, EAN-8, Interleaved 2 of 5, More through Brady WorkStation, UPC-A, UPC-E |
| Calibration Required? | Automated through Smart Cell |
| Color Printing Capability | Single Color |
| Font Sizes | 4 - 170 pt |
| Font Styles | Brady Alpine, Brady Fixed Width |
| Label Retention Feature | Yes |
| Maximum Labels per Day | 1000 |
| Maximum Label/Tape Width | 1.5 in |
| Maximum Print Speed | 1.50 in/s |
| Minimum Label Length | 0.240 in |
| Maximum Printed Label Length | 39.00 in |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| Compatibility | |
| Compatible Media | M4-, M4C-, M5-, M5C- |
| Label Material Types | BradyGrip® Polyester, FreezerBondz™ Polyester, Heat-shrink Polyolefin, Metallized Polyester, Nylon Cloth, Polyester, Polypropylene, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth, Water Dissolvable Paper |
| Materials Supported | Continuous, Die-cut |
| Custom Labels Available | No |
| Maximum Print Width | 1.44 in |
| Software Compatibility | Brady Workstation |
| Languages Available | Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Italian, Japanese, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (Mexico), Swedish, Turkish |
| What's Included | |
| Software Package | Basic Design Suite |
| Includes | (1) AC Adapter (M41-51-61-AC), (1) Indoor/Outdoor Vinyl Label Cartridge (M5C-1500-595-WT-BK), (1) M510 Printer, (1) Quick Start Guide, (1) Rechargeable NiMH Battery Pack (M-NIMH-BATTERY), (1) USB Cable (M-USB-103788), (1) USB Flash Drive with Driver and User Manual, (1)Brady Workstation Design & Print Essentials Insert |
| Model | M510 |
| Warranty | 2 Years |
| Compliance | |
| California Prop 65 | Prop 65WARNING: Risk of cancer and reproductive harm from exposure to Lead. See www.p65warnings.ca.gov. |
| REACH SVHC Status | Part contains an SVHC |
| REACH Candidate List Date | 21 January 2025 |
| Country of Origin | Malaysia |
| ECCN | EAR99 |
| HTS Code | 8443.32.1050 |
| RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
| UNSPSC | 45101520 |
